S-Series

By the optimally designed optics and electronics, even the small 1/10 "sensor in housings with a diameter of just 2.75 mm provides impressive pictures...

to our S-Series

M-Series

The modules of our M-series are our smallest cameras with HD or Full HD resolution. Sensors with 1/11 ", 1/9" and 1/6 "are used in modules in sizes from 3.2 mm...

to our M-Series

L-Series

Due to the high resolution of up to 8MP, their light sensitivity and the ability to be combined with a wide range of lenses and accessories, the L-series cameras can be used very flexibly while havinging small sizes...

to our L-Series

S-Series

Pro Cam

From the 400x400 pixels of the small 1/10" sensor can get impressive images because of the optimized optics. The standard lenses generate high depths of field and can also be set up for short working distances. By the high light sensitivity of the sensor the camera can be also used with lower light conditions.

As an option NIR version is also available, whereby the camera automatically switches to b/w mode when switching to NIR lighting.

data sheets

By viewing the video, you agree that your data will be transmitted to YouTube and that you have read the privacy policy.

modules with a diameter of 2.75 and 3.2 mm
1/10" CMOS sensor (color) / 400 x 400 px
USB (UVC) or CVBS interface
as standard with HQ lenses for maximum depth of field (FOV ~ 120 ° or ~ 45 °); 0 ° view direction
very sensitive and therefore also useable in lower light conditions
NIR version available as option
individualized variations and customized modules available

Typical Applications

Endoscopy

Medical Technology

Metrology

Industrial Imaging and Machine Vision

Inspection and Condition Monitoring

Beispielbild S-series - 10 µm Glasmaßstab aus 1 mm Abstand — 10 µm increments of a glass scale

Beispielbild S-series - Smartphone-Display aus 1 mm Abstand — Smartphone-Display aus 1 mm Abstand

Beispielbild S-series - Banknote aus 20 mm Abstand — Banknote aus 20 mm Abstand

Beispielbild S-series - Blüten im Abstand von 40 mm — Blüten im Abstand von 40 mm

Example Snapshots

These snapshots were taken with a S-Series camera (120° HQ-lens) in different distances.

M-Series

Pro Cam

The modules of this M-Series are the smallest cameras with Full HD or HD resolution. They often are used as basis for individual variations or completely customized vision-systems.

We also offer solutions for integrated illumination units as an option, which are advantageous given the small pixel sizes of the sensors used.

In addition to USB cameras, M-series models with CVBS interface are available for a direct connection to monitors. The M series is very diverse and contains not only cameras with a view straight ahead, but also designs with a 90° view angle. Models with VGA, 720p and 1080p resolution are available. In addition to the color cameras with rolling shutter, the M-Series also contains a monochrome global shutter camera.

data sheets

By viewing the video, you agree that your data will be transmitted to YouTube and that you have read the privacy policy.

Product Variants

M-Series CVBS (1/4“ CMOS color)
M-Series VGA (1/9“ CMOS color) with and without integrated LED illumination
M-Series HD 720p USB (1/11“ CMOS b/w and color)
M-Series HD 720p USB or OTG (1/9“ CMOS color)
M-Series HD 1080p with 30 fps USB or OTG (1/6“ CMOS color)
M-Series HD 1080p with 60 fps USB or OTG (1/6“ CMOS color)
M-Series GS with global shutter (1/7.5“ CMOS b/w)

CVBS module with Ø 16 mm (S-mount lens) or square with 10x10 mm => HQ lens, adjustable (M5.5)
VGA module (USB) with Ø 5.95 mm, fixed built-in lens and dimmable LED illumination or without LEDs and with adjustable lens
VGA MIC module (USB) with adjustable lens of larger focal lengths in housing with Ø 6.5 mm or Ø 10 mm with integrated LED illumination
720p module (USB) with Ø 3.2 and 4.2 mm => HQ lens fixed in the housing
1080p module (USB; 30 fps or 60 fps) with Ø 6.5 mm or square with 6.5 x 6.5 mm => HQ lens, adjustable (M5.5)
1080p module (USB; 30 fps or 60 fps) for 90 ° view with 10x6x30 mm => HQ lens, adjustable (M5.5)
VGA module (USB; b/w) with global shutter for 90 ° view with 10x6x30 mm => HQ lens, adjustable (M5.5)
individualized variants and customized modules available

Typical Applications

Endoscopy

Metrology

Inspection and Condition Monitoring

Industrial Imaging and Machine Vision

Analytics

Microscopy

Example Snapshots

These snapshots were taken with M-Series cameras

L-Series

Pro Cam

Due to the high resolution of up to 8 megapixels, the high light sensitivity and the fast acting automatics in these small modules, the L-series can be used very flexibly.

They can be integrated in machines, robots or automated systems, or they can be used as stand-alone devices. They can be also used as a digital microscope or for process and assembly monitoring.

The product range contains 5 MP and 8 MP USB cameras as well as a Full HD version with HDMI interface.

All L-series cameras have an S-mount and can by that be used with a wide range of different lenses. In addition to our lenses, which were optimized for these modules, simpler basic and standard optics can also be used. We also offer adaptors for C-Mount and RMS lenses for having additionally the possibility to use such standard lenses. This creates maximum flexibility for the use of our L-series cameras and for a wide range of applications.

As optional accessories for the L series, we offer a wide range of lenses, tube extenders, thread adaptors, mounts, special cable and LED illuminations.

data sheets

By viewing the video, you agree that your data will be transmitted to YouTube and that you have read the privacy policy.

L-Series 5MP USB (1/4 “CMOS color)
16 x 16 x 35 mm
L-Series 5MP Pro USB (1/4“ CMOS color) also contains a snapshot switch and a trigger input
L-Series 8MP USB (1 / 3.2 “CMOS color)
22 x 22 x 40 mm
L-Series 1080p HDMI (1 / 2.9 “CMOS color)
20 x 20 x 60 m

Customized variants and individualized systems are available. There is a wide range of lenses to choose from.
